[HB-CTE-C150B] HYPER CTE 1/8 CAGE TRUGGY ELECTRIC RTR- BLACK ROLL CAGE

STANDARD PARTS
OPTIONAL PARTS
MANUAL
EXPLODED VIEW
ROLL CAGE EXPLODED VIEW

[FEATURES]

• Full aluminium roll cage
• Aluminium chassis side guards
• Stealth grey anodised parts
• Differentials: Three
  -. Front differential filled with #5000 silicone oil.
  -. Center differential filled with #7000 silicone oil.
  -. Rear differential filled with #5000 silicone oil.
• Turnbuckles
• 4mm Alu F/R shock towers
• Highly efficient drivetrain
• Lightweight centre drive shaft
• F/R anti roll bars
• C-hub design
• 17mm big bore shocks
  -. Filled with #600 silicone oil.
  -. Front Spring: 1 kg/cm, L=65mm, Orange (#OP-0045)
  -. Rear Spring: 0.84 kg/cm, L=85mm, Orange (#92013)

• Battery box
• Adjustable motor mount

[SPECIFICATIONS]

Length: 550mm
Width: 415mm
Height: 205mm
Wheelbase: 360mm
Front track: 340mm
Rear track: 355mm

[REQUIREMENTS]

• LiPo batteries with single XT90 plug connector
• Battery Charger
• AA Batteries for Transmitter (4)
